RELE VERT 12V 1 TRF 12A/400VAC

859e50fbbcfd1482afa62bf363632355

fd759be5493e6f677b8f35bd44167b3a

859e50fbbcfd1482afa62bf363632355

fd759be5493e6f677b8f35bd44167b3a

Esgotado

€5,57

Sob Consulta

Não existe stock de momento, caso pretenda receber notifição clique seguinte botão Faça Login

Leiria Coimbra

ref: 7631C12DE

Descrição

Contact: SPDT Rated Current: 12A Housing: 29x12,7x15,7mm

. 12A SPDT miniature power relays

. Wash tight version

. Dielectric strength: 5000Vrms

. Low height:15,7mm

. Isolation spacing greater than 10mm

. Proof tracking index (PTI/CTI) 250

. Surpasses requirements of VDE 0631/0700

Ficha Técnica

Technical Specifications



Contact:	SPDT
Contact Material:	AgNi
Rated Current:	12A
Max. Switching Voltage:	400V AC / 300V DC
Max. Switching Power:	3000VA / 360W
Operate/Release Time:	7/3ms
Testing Voltage (FCC)
Coil/Contact:	5000V_RMS
Open Contacs:	1000V_RMS
Lifetime
Mechanical, Min.:	3x10⁷ Operations
Electrical, Min. (12A / 250V AC):	1x10⁵ Operations
Operating Temperature:	-40...+90°C
Max. Solder Temperature:	270°C (5s)
Weight Approx.:	14g
